Access Unit für 2 Griffe und/oder Kartenleser Legic®; 3000-U47-08

Dieses Produkt hat keine gültige Kombination.

Produkthinweis:

Direct connection of 2 series Agent E Wired swinghandles
Control of the central LED in the handle via terminal block on the rear side
Alternatively, connection of 2 electromechanical locks and 2 external card readers
Max. 32 Access Units er Control Unit Wireless
Administration of up to 64 handles via one IP address

Power supply: 12 ... 24 VDC, 200 mA + outputs
Handle outputs: 2 (RJ45), max. 12 V / 1,000 mA, or
Max. 24 V / 500 mA per output
Port for card reader: 1 (pin terminal) Legic®
CAN bus ports: 2
Operating temperature: +5 ... +45 °C
Dimensions (L x B x H): 107 x 135 x 33 mm
Scope of delivery: Reading antenna with two RFID cards; Assembly bracket
